| Welche Kette wird benötigt: |
|
|
| |
|
|
|
|
| Ritzel vorne |
Ritzel hinten |
Kette - Glieder |
spannen nach |
|
| Front sprocket |
Crownwheel |
Chain (links) |
push |
|
| |
|
|
|
|
| 15 |
46 |
80 |
oben/up |
(standard for all models, except DL/GP200) |
| 16 |
46 |
81 |
unten/down |
|
| 17 |
46 |
82 |
oben/up |
|
| 18 |
46 |
82 |
unten/down |
|
| 19 |
46 |
82 |
oben/up |
|
| 20 |
46 |
83 |
unten/down |
|
| 21 |
46 |
83 |
oben/up |
|
| 22 |
46 |
84 |
unten/down |
|
| |
|
|
|
|
| 15 |
47 |
81 |
unten/down |
|
| 16 |
47 |
81 |
oben/up |
|
| 17 |
47 |
82 |
unten/down |
|
| 18 |
47 |
82 |
oben/up |
(standard for DL/GP200) |
| 19 |
47 |
83 |
oben/up |
|
| 20 |
47 |
83 |
unten/down |
|
| 21 |
47 |
84 |
unten/down |
|
| 22 |
47 |
84 |
unten/down |
|
